VPC Private Connectivity

VPC Peering

VPC Peering connects two VPCs privately using AWS network

• It makes them behave as if they were in the same network
• Peered VPCs can be in the same AWS region or across AWS regions
• You can do VPC peering with another AWS account

Important:

• VPC CIDRs should not overlap!
• You must update route tables in each VPC’s subnets to ensure instances can communicate across VPCs

One VPC is the Requester VPC and the other VPC is the Accepter VPC.

Note: Enabling DNS support for VPC peers in the peering connection allows the private IP usage to be forced, if applications always use the instance public DNS name.

VPC peering limitations:

• Must not have overlapping CIDRs
• VPC Peering connection is not transitive (must be established for each VPC that need to communicate with one another)
• You can setup only 1 VPC peering connection between 2 VPCs

• Maximum 125 VPC peering connections per VPC

• VPC-A VPC-B <VPN/DX> Corporate. Traffic from VPC-A cannot cross VPC-B to reach Corporate in this scenario.
• VPC VPC-B (IGW). Traffic from VPC-A cannot use VPC-B's IGW. Same if we replace IGW with NAT GW.
• VPC VPC-B (Endpoints). Traffic from VPC-A cannot use VPC-B's endpoints to services such as S3 & DynamoDB

VPC Endpoints

VPC Endpoints provide connectivity between VPC and AWS services.

• Endpoints allow you to connect to AWS Services using a private network instead of the public network
• They remove the need of IGW or NAT GW to access AWS Services

• Endpoint devices are horizontally scaled, redundant and highly available without any bandwidth constraint on your network traffic

  • Gateway Endpoint: provisions a target and must be used in a route table. Only S3 and DynamoDB
  • Interface Endoint: provisions an ENI (private IP) as an entry point - most other AWS services

Gateway Endpoints

• Enables private connection between VPC and S3 or DynamoDB
• Need to modify the route tables and add an entry to route the traffic to S3 or DnamoDB through the gateway VPC endpoint
• When we create an Amazon S3 endpoint, a prefix list is created in VPC
• The prefix list is the collection of IP addresses that Amazon S3 uses
• The prefix list is formatted as pl-xxxxxxxx and becomes and available option in both subnet routing tables and Security Groups
• Prefix list should be added in Security Group Outbound rule (if Security group outbound rules do not have default “Allow All” rule)

VPC Endpoint Security

• Endpoint allows more granular access to VPC resources as compared to broad access through VPC peering connection
• Access to S3 through VPC endpoint can be secured using bucket policies and endpoint policies
• VPC Endpoint policy:
  • An IAM policy which is attached to VPC endpoint
  • Default policy allows full control to the AWS service

Interface Endpoints

• Interface endpoints create local IP addresses (using ENI) in the VPC
• You create one interface endpoint per Availability Zone for high availability
• There is per hour cost (~$0.01/hr per AZ) and data processing cost (~$0.01 GB)
• Uses Security Groups - inbound rules
• For interface endpoints, AWS creates Regional and zonal DNS entries that resolves to private IP addresses of interface endpoints
• Interface endpoints support only IPv4 traffic
• Interface VPC endpoints support traffic only over TCP

VPC PrivateLInk
